Turnbuckle with Jaw & Eye

Reliable Tensioning Solution for Rigging & Lifting

Turnbuckle with Jaw & Eye

Tuigmeester’s Jaw & Eye Turnbuckles are engineered to provide robust, adjustable connections for a wide range of applications. Designed for durability and ease of use, these turnbuckles deliver safety and stability, making them ideal for lifting, securing, and tensioning tasks.
Download our Brochure
Download Brochure

Turnbuckle with Jaw & Eye

Application

Connect Jaw End

Secure the jaw end by placing it around a pin or ring and locking it with the included cotter pin.

Connect Eye End

Attach the eye end to a compatible hook, chain, or other fitting.

Adjust Tension

Twist the turnbuckle body to increase or decrease tension until desired tightness is achieved.

Secure with Locknuts

Tighten the locknuts to prevent unintentional loosening.

Key Features :

  • Heavy-Duty Construction : Made from forged carbon steel, quenched, and tempered for enhanced strength and durability.
  • Corrosion Resistance : Hot dip galvanized finish protects against rust and wear, ensuring long service life.
  • Safety Factor 5:1 : Built to handle high loads, with Minimum Break Load (MBL) 5 times the Working Load Limit (WLL) and Proof Load 2.5 times the WLL.
  • Easy Adjustment : Jaw & eye design allows easy tension adjustment and quick connection for rigging tasks.
  • Locknut Included : Comes with locknuts to secure both ends, providing added safety and stability.
